Helical Worm Gearbox

Helical worm gearbox yog ib hom kev ceev reducer uas siv kev sib xyaw ua ke ntawm helical iav thiab cab iav rau lub zog xa mus. Los ntawm ntau-theem iav meshing, nws ua tiav qhov qis qis thiab siab torque tso zis, thaum tseem sib txuas cov kev ua haujlwm siab thiab kev ua haujlwm du ntawm cov iav helical nrog rau qhov sib kis loj thiab nws tus kheej -locking function of worm gears. Nws yog ib qho khoom siv feem ntau hauv kev lag luam kis kab mob uas sib npaug txo qis, qhov xav tau ntawm qhov chaw, thiab kev ruaj ntseg.







Qauv	Output Ncej Dia. (mm)		Hwj chim	Piv txwv	Max. Torque
	Khoom Ncej	Hollow Ncej	(kW)	(i)	(Nm)
S37	20 hli	20 hli	0.18~0.75	10.27~152	90
S47	25 hli	25/30 mm	0.18~1.5	11.46~244.74	170
S57	30 hli	30/35 hli	0.18~3	10.78~196.21	295
S67	35mm ib	40/45 hli	0.25~5.5	11.55~22	520
S77	45mm ib	50/60 hli	0.55~7.5	9.96~241.09	1270
S87	60 hli	60/70 hli	0.75~15	11.83~222	2280
S97	70 hli	70/90 hli	1.5~22	12.75~230.48	4000





• Qhov sib piv ntawm cov iav siab, ua rau txo qis ceev: Ib qho kev sib kis ntau- theem sib txuas ua ke nrog cov iav iav thiab cov iav helical tuaj yeem txo qhov kev sib hloov ceev ntawm lub cev muaj zog, ua rau nws tsim nyog rau cov ntawv thov uas xav tau qis ceev thiab siab torque.
• Kev ua haujlwm du thiab tsis tshua muaj suab nrov: iav loj qhov chaw tiv tauj thiab cuam tshuam tsawg kawg txo kev co thiab suab nrov thaum lub sij hawm siab - kis tau tus mob.
• Tus kheej -locking muaj nuj nqi kom muaj kev nyab xeeb siab: nws tiv thaiv cov cuab yeej los ntawm kev txav ntawm nws tus kheej tom qab kaw, txhim kho kev nyab xeeb thiab kev ntseeg siab ntawm cov khoom siv ua haujlwm.



Dab tsi yog qhov txawv ntawm Helical worm gearbox thiab Helical bevel gearbox

1. Cov qauv tsim thiab kev teeb tsa

S Series: Ntau cov qauv compact thiab hnav, haum rau qhov chaw - txwv ib puag ncig.

Cov vaj tse nyob nrog cov cua txias rau kev co nqus, qhov kub thiab txias tsis tshua muaj suab nrov.

Flexible installation: taw, flanges, hollow shafts, torque caj npab, thiab lwm yam.

K Series: Muaj zog vaj tse rigidity thiab zoo heev hnyav - lub peev xwm.

Modular tsim nrog ntau yam kev xaiv tso zis (khoom / hollow shafts, flanges).

tuaj yeem ua ke nrog R Series kom nthuav dav qhov sib piv ceev thiab lub zog.



2. Cov xwm txheej ntawm daim ntawv thov

S Series (Self-locking Priority): Cov cuab yeej siv los tiv thaiv- thim rov qab / tso nws tus kheej- xauv: conveyors, elevator, theem tshuab, rooj vag, ntim tshuab.

Compact qhov chaw, qis mus rau nruab nrab lub zog, kev kub ceev piv scenarios: automated ntau lawm kab, neeg hlau pob qij txha, me me lifting khoom.

K Series (Hnyav-lub luag haujlwm thiab siab-efficiency): Lub zog muaj zog, siab lub zog siab, tsis tu ncua hnyav: metallurgy, mining, cement, chaw nres nkoj machinery, cranes, khoom siv sib xyaw.

High-precision, siab- kis tau tus mob: textiles, luam ntawv, ua zaub mov, hnyav- lub luag haujlwm conveying tshuab.





Qauv	Helical cab iav gearbox
Ambient	-40 ~ 50 degree
Qhov siab	1000 m
Ua Haujlwm Ua Haujlwm	S1 (Nruam)
Cov av noo	Tsawg dua lossis sib npaug li 91%
Hom tswv yim	Flange, lub cev muaj zog, khoom ncej
Warranty	12 lub hlis / 1 xyoos





















Cim npe nrov: Tuam Tshoj helical worm gearbox manufacturers, lwm tus neeg, Hoobkas
